HEINE BETA 200 LED Retinoscope

Precision streak retinoscope for professional objective refraction

The HEINE BETA 200 LED Retinoscope is a professional handheld streak retinoscope for objective refraction. Designed for fast and easy observation of the fundus reflex, it combines HEINE precision optics with bright, homogeneous LEDHQ illumination.

The BETA 200 LED enables the objective assessment of refractive errors such as myopia, hyperopia and astigmatism. Retinoscopy is particularly valuable when examining children or patients for whom reliable subjective refraction is difficult or impossible.

Precise streak for clear observation of the fundus reflex

1.1 mm streak width and 35 mm streak length

A key feature of the HEINE BETA 200 LED is its bright and precisely defined streak.

HEINE specifies a typical streak width of 1.1 mm and a streak length of 35 mm. The streak width is below the 1.5 mm limit specified in ISO 12865.

The clearly defined streak supports fast and reliable observation of the fundus reflex and precise assessment during retinoscopy.

ParaStop for precise parallel beam adjustment

A defined setting for efficient examination

The BETA 200 LED features HEINE ParaStop technology.

ParaStop allows the examiner to precisely set the parallel beam, providing a defined reference position for objective refraction.

This is particularly useful in routine ophthalmic practice, where precise and reproducible adjustment contributes to efficient examination workflows.

LEDHQ – bright and homogeneous illumination

HEINE equips the BETA 200 LED with its LEDHQ technology.

The illumination provides bright, homogeneous light for a clearly visible fundus reflex. Uniform illumination supports reliable observation and interpretation of the reflex during objective refraction.

Continuous brightness adjustment from 3 to 100%

The light intensity can be continuously adjusted from 3 to 100%.

This allows the examiner to adapt illumination to different examination conditions rather than working with a fixed light intensity.

Polarisation filter to reduce distracting reflections

An integrated polarisation filter reduces stray light and internal reflections.

This helps provide an unobstructed view of the fundus reflex during examination.

The design of the instrument also helps shield the examiner’s eye from unwanted ambient light, further supporting comfortable observation.

Objective determination of refractive errors

The HEINE BETA 200 LED is specifically designed for the objective determination of the eye’s refractive status.

Unlike subjective refraction, the examiner does not have to rely on the patient being able to accurately compare different corrective lenses.

Retinoscopy can be used to objectively assess:

• myopia;
• hyperopia;
• astigmatism.

This makes the BETA 200 LED particularly useful for professional refractive diagnostics and examination situations in which patient communication or cooperation is limited.

Particularly valuable in paediatric ophthalmology

Objective refraction has an important role in paediatric ophthalmology, especially when examining young children.

Subjective refraction requires the patient to reliably compare and communicate different visual impressions. Infants and young children may not be able to provide this information.

Retinoscopy enables the examiner to assess refractive status objectively, making the BETA 200 LED particularly suitable for:

• ophthalmology practices;
• eye clinics;
• paediatric ophthalmology;
• strabismus assessment;
• ophthalmology outpatient departments;
• professional refractive diagnostics.

One-finger operation for vergence and streak rotation

Intuitive control during examination

HEINE has designed the BETA 200 LED for straightforward operation during retinoscopy.

Vergence and streak rotation can be controlled with a single operating element, allowing convenient adjustment with the thumb.

This one-finger operation enables the examiner to modify the streak directly while continuing to observe the reflex.

Dynamic retinoscopy

An optional fixation card holder and fixation cards are available for the HEINE BETA 200 LED.

These accessories allow the instrument to be used for dynamic retinoscopy, extending its applications in professional refractive assessment.

Durable design for professional daily use

The BETA 200 LED is designed for long-term professional use in ophthalmology practices and clinics.

Important construction features include:

• metal operating controls;
• maintenance-free design;
• dustproof housing;
• long-lasting LEDHQ illumination;
• 5-year HEINE guarantee.

The instrument weighs approximately 90 g and measures 129 × 37 × 43 mm, making it compact for everyday handheld examination.

Flexible power options

The HEINE BETA 200 LED can be integrated into the HEINE power supply system.

Depending on the selected configuration, the instrument can be combined with compatible battery handles and rechargeable BETA handles.

Rechargeable configurations can be used with appropriate USB charging solutions or HEINE desktop chargers. Compatibility with HEINE power systems makes the BETA 200 LED particularly attractive for practices and clinics already using other HEINE diagnostic instruments.

HEINE BETA 200 LED – key specifications

Why choose the HEINE BETA 200 LED?

The BETA 200 LED focuses on what matters most in professional retinoscopy: a clearly visible fundus reflex combined with precise and intuitive control.

Its key advantages include:

LEDHQ + 1.1 mm streak + ParaStop + polarisation filter + continuous brightness control + one-finger operation

This combination makes the HEINE BETA 200 LED a high-quality instrument for regular objective refraction in professional ophthalmology.

Frequently asked questions about the HEINE BETA 200 LED

What is the HEINE BETA 200 LED used for?

The HEINE BETA 200 LED is a handheld streak retinoscope designed for the objective determination of refractive errors and observation of the fundus reflex.

Which refractive errors can be assessed?

Retinoscopy can be used to objectively assess myopia, hyperopia and astigmatism.

What is HEINE ParaStop?

ParaStop allows precise adjustment of the parallel beam, providing the examiner with a defined setting for retinoscopy.

How wide is the light streak?

HEINE specifies a typical streak width of 1.1 mm and a streak length of 35 mm.

Can the brightness be adjusted?

Yes. The LEDHQ illumination can be continuously adjusted from 3 to 100%.

Does the BETA 200 LED have a polarisation filter?

Yes. The integrated polarisation filter helps reduce stray light and internal reflections during examination.

Can the BETA 200 LED be used for dynamic retinoscopy?

Yes. HEINE offers optional fixation cards and a fixation card holder for dynamic retinoscopy.

Is the BETA 200 LED suitable for paediatric ophthalmology?

Yes. Objective refraction is particularly valuable when examining young children because it does not depend on reliable subjective responses from the patient.

What guarantee does HEINE provide?

HEINE specifies a 5-year guarantee for the BETA 200 LED Retinoscope.

HEINE BETA 200 LED Retinoscope at V-MEDTECH

The HEINE BETA 200 LED Retinoscope is a premium solution for ophthalmologists, eye clinics and specialist departments requiring reliable objective refraction.

Its combination of a precise 1.1 mm streak, LEDHQ illumination, ParaStop, polarisation filter, continuous brightness adjustment and intuitive one-finger operation makes the BETA 200 LED a purpose-built professional instrument for retinoscopy.

For practices and clinics already using HEINE diagnostic instruments, compatibility with the HEINE handle and charging ecosystem provides an additional advantage for everyday clinical use.
